Specification
| function |  | |  |
| TEKNA series | KOMBA | TEKBA series | |
| series | AKS hand movement | DMS hand movement | EMS hand movement |
| description | APG 4–20MA, AKL with liquid level interface and built-in TPR PH/ORP | DML with liquid level interface, DMC pulse signal, DMM 4–20mA | EML with liquid level interface, EMC pulse signal, EMM 4–20mA |
| Pump head material | pvdf | pvdf | pvdf |
| Film material | PTFE | PTFE | PTFE |
| Valve ball | pottery and porcelain | pottery and porcelain | pottery and porcelain |
| Flow / Pressure | 5001：5 L / 6 BAR；6007L / 8 BAR；6038L / 2 BAR；80018L / 1 BAR；803110L / 0.1 BAR | 9 L / 3 BAR；1 L / 7 BAR | 6007L / 8 BAR；6038L / 2 BAR；80018L / 1 BAR；803110L / 0.1 BAR |
| source | 100–240V | ||
| frequency | 50/60HZ | ||
| seal components | FPM/EPDM (optional) | ||
| interface dimensions | 4*6*12 (803 series) | 4*6 | 4*6*12 (803 series) |
| power | 15W–40W | 14W | 20W–40W |
| way to install | Wall-mount/standing | Standing / wall-mounted (optional) | Wall-mount/standing |
