Specification
| function |  |  |  |  |
| Ion concentration meter | transmissionter | Disabled oxygen meter | metal ethers meter | |
| model | IT8310RS | TC7310 | DC5310RS | CT6310RS |
| measuring range | 0-16PH±1999MV | 0-2000MS 0-20 megohms | 0-40mg/L0-200ug/L | 0-100pppm |
| resolution ratio | 0.01PHMW | 0.01/0.1/1.0 | 0.01mg/L0.1ug/L | 0.001/0.01/0.1 |
| accuracy | ±0.01PH±1MV | ±1% | ±0.02 | ±0.5% |
| temperature composition | PT1000 | |||
| Relay alarm | 2 road highs and lows | |||
| analog output | 2 roads 4-20MA (PH/T) | |||
| digital output | Standard MODBUS-RTU RS485 | |||
| Cleaning of contacts | have | |||
| Data preservation | 50 group event records (RS exclusive) | |||
| source | 90–260V | |||
| language | Chinese / English / Tradisional | |||
| way to install | Wall-mounted piping panels | |||
| size mm | 144*144*115 | |||
| Opening size mm | 138*138 | |||
| levels of protection | IP65 | |||
